The Sleeve Anchor with Hex Flange Nut (commonly referred to as a “Flange Sleeve Anchor” or “Serrated Nut Anchor”) is an upgraded masonry fastener designed for speed and security. Unlike standard anchors that require a separate washer, the Sleeve Anchor with Hex Flange Nut features an integrated wide-base nut. This design not only eliminates the risk of losing washers during high-altitude installation but also provides superior load distribution and vibration resistance.
Product Overview: Manufactured from Carbon Steel with a durable Yellow Zinc Plating, this heavy-duty anchor is ideal for fastening metal brackets, gate tracks, and machinery to concrete. The flange nut often includes a serrated bearing face, which bites into the fixture surface to act as a mechanical lock against loosening.
Sleeve Anchor with Hex Flange Nut Specifications
| Product Name | Sleeve Anchor with Hex Flange Nut / Flange Head Anchor |
| Head Style | Hex Flange Nut (Integrated Washer Face) |
| Material | Carbon Steel (Grade 4.8 / 5.8) |
| Finish | Yellow Zinc Plated (Passivated) |
| Benefit | Anti-Vibration & Fast Installation |
Engineering Insight: Why use a Flange Nut?
The Sleeve Anchor with Hex Flange Nut solves two common job-site problems:
- The “Missing Washer” Issue: When installing standard anchors overhead, washers often fall off and get lost. The flange nut is one solid piece, making installation faster and less frustrating.
- Load Distribution: The wide flange covers oversized holes in the fixture plate. Standard nuts might pull through a large hole, but the flange spans the gap securely, providing a stronger hold on thin metal channels or brackets.
For more details on nut types, please refer to the Flange nut entry on Wikipedia.
Installation Guide
- Drill: Drill a hole of the same diameter as the anchor sleeve (e.g., 10mm bit for M8 anchor).
- Clean: Remove dust to ensure maximum grip.
- Insert: Hammer the Sleeve Anchor with Hex Flange Nut through the fixture until the flange rests against the surface.
- Tighten: Tighten the flange nut. The integrated washer face will clamp down firmly while the bottom cone expands the sleeve.
Frequently Asked Questions (FAQ)
Q: Is the flange serrated?
A: Typically, yes. Most of our flange nuts feature under-head serrations to prevent back-off caused by machine vibration or wind loading.
Q: Can I remove it?
A: Yes. You can unscrew the flange nut and remove the fixture. The threaded stud will remain protruding from the floor/wall, ready for re-attachment.
Need Flange Sleeve Anchors?
Handan Bolt manufactures high-quality Sleeve Anchors with Hex Flange Nut in sizes M6, M8, M10, and M12. Perfect for garage door tracks and racking.
